SRC-370SH-4730 Factory Hot Selling 4.5V 17500rmp 3.63A Output 11.51W

Product Description

PMDC MOTOR Technical Data
Model		Rated Voltage (V)		No-Load		Rated				Stall
		Operating Range	Nominal	Speed	Current	Speed	Current	Torque	Power	Current	Torque
		Operating Range	Nominal	RPM	mA	RPM	mA	mN.m / gf.cm	W	mA	mN.m / gf.cm
RF-370CA	061700	6.0~24.0	24 VDC	1320	3	1000	8	0.98/10	0.1	260	4.02/41
RC-370CH	20123	3.0~6.0	6 VDC	8000	70	6878	420	2.4/24.5	1.71	2550	17/173
RC-370SH	4730	3.0~5.0	4.5 VDC	17500	550	15199	3630	7.2/73.4	11.51	24000	55/561
RC-370SH	18139	6.0~12.0	12 VDC	10000	130	8439	700	5.8/59.2	5.17	3800	37.5/382.5

Refer to the technical parameters in the table above for more detailed configuration options.

Application Details

Frequently Asked Questions (FAQ)

What are the main specifications of the RC-370SH-4730 motor?

The RC-370SH-4730 operates on a nominal voltage of 4.5 VDC. It has a no-load speed of 17,500 RPM with a 550 mA no-load current. At its rated load, it yields a speed of 15,199 RPM, 3.63A (3630 mA) current, and 11.51W power output.

What is the operating voltage range for the 370SH-4730 motor?

The operating range for the 4730 model is between 3.0V and 5.0V DC, allowing flexibility depending on your device's power configuration.

How does the RC-370SH-18139 model compare in performance?

The RC-370SH-18139 model operates at a nominal voltage of 12 VDC (operating range 6.0V to 12.0V). It provides a no-load speed of 10,000 RPM, a rated speed of 8,439 RPM, and a rated power output of 5.17W.

What is the stall torque of the RC-370SH-4730?

The stall torque of the RC-370SH-4730 is 55 mN.m (approx. 561 gf.cm), which represents its maximum torque output when stalled.

Can these PMDC motors be customized for different applications?

Yes, the 370 motor series offers different configurations (such as RF-370CA and RC-370CH) that cover operating ranges from 3.0V up to 24.0V DC to suit various gearboxes and applications.
